Manual for QW-D41F472B-DE

Manual for QW-D41F472B-DE

Brand: SHARP

Category: Home Appliances

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:21 p.m.

Warranty Information

Consult your local service center for warranty information.

Preparing for First Use:

  • Ensure electricity and water supply match specifications.
  • Remove all internal packaging.
  • Set water softener level and fill rinse aid compartment.

Filling Salt:

  • Open salt compartment, add 1kg salt and water.
  • Replace cap. Refill every 20-30 cycles.

Detergent Usage:

  • Use dishwasher-specific detergents.
  • Add recommended amount. Store in a cool, dry place.

Loading:

  • Place large, heavily soiled items in the lower basket.
  • Place delicate items in the upper basket.
  • Load cutlery individually, sharp points down.

Programmes:

  • Select the most suitable programme based on soil level and dish type.
  • Refer to the programme table for details.

Control Panel:

  • Use Power On/Off, Programme Selection, and feature buttons.
  • Indicators show programme status and salt/rinse aid levels.

Troubleshooting and error codes

FAULTPOSSIBLE CAUSETROUBLESHOOTING
The programme does not start.Your Dishwasher is not plugged in.Plug your Dishwasher in.
Your Dishwasher is not switched on.Switch your Dishwasher on by pressing the On/Off button.
Fuse blown.Check your indoor fuses.
Water inlet tap is closed.Turn on the water inlet tap.
Your Dishwasher door is open.Close the Dishwasher door.
Water remains inside the machine.Water inlet hose and machine filters are clogged.Check the water inlet hose and machine filters and make sure they are not clogged.
Water drain hose is clogged or twisted.Check the drain hose, then either clean or untwist it.
The filters are clogged.Clean the filters.
Machine stops during washing.The programme is not finished yet.Wait until the programme is finished.
Power failure.Check mains power.
Shaking and hitting noises are heard during a wash operation.The spray arm is hitting the dishes in the lower basket.Move or remove items blocking the spray arm.
Partial food wastes remain on the dishes.Dishes placed incorrectly, sprayed water not reaching affected dishes.Do not overload baskets.
Dishes leaning against each other.Place dishes as instructed in the section on loading your dishwasher.
Not enough detergent used.Use the correct amount of detergent, as instructed in the programme table.
Whitish stains remains on dishes.Rinse aid dosage and/or water softener setting set too low.Increase rinse aid and/or water softener level.
High water hardness level.Increase water softerner level and add salt.
Salt compartment cap not closed properly.Check that the salt compartment cap is closed properly.
Dishes do not dry.Drying option is not selected.Select a programme with a drying option.
Rinse aid dosage set too low.Increase rinse aid dosage setting.
Stainless-steel quality of the dishes is insufficient.Use only dishwasher-proof sets.
Rust stains form on the dishes.High level of salt in wash water.Adjust the water hardness level using water hardness table.
Salt compartment cap not closed properly.Check that the salt compartment cap is closed properly.
Too much salt spilled in the Dishwasher while filling it with salt.Use funnel while filling salt to the compartment to avoid spillage.
A poor mains grounding.Consult a qualified electrician immediately.
Detergent remains in the detergent compartment.Detergent was added when the detergent compartment was wet.Make sure detergent compartment is dry before use.
