Features
- Compact design and small area for operation.
- Fast warm-up time (30 sec or less) and first copy time (5.9 sec).
- Automatic document feeder (SF-2214 only) for increased productivity.
- Integrated photoconductor and peripheral parts, eliminating the need for developer replacement.
- Simplified fuser and paper feed section maintenance.
- Energy saving mode and quiet operation (46 dB).
- User-selectable operating conditions via user simulation.
Novel Technology
- Novel two-component development system for continuous developer substitution without replacement.
- Single Pass Feeder (SPF) for automatic document feeding and one-set copying.
Novel Functions
- Power Save Function: Operates after a set time of inactivity to save energy. Includes two modes: Pre-heat and Auto power shut off.
Troubleshooting and error codes
| No. | Abbreviation | Function | Type | Operation |
|---|---|---|---|---|
| 1 | POD | Paper out sensor | Transmission photo sensor | H when paper is sensed. |
| 2 | MHPS | Mirror home position sensor | Transmission photo sensor | H at the home position. |
| 3 | SDSW | SPF cover open/close sensor | Lead switch | H when the cover is open. |
| 4 | SPOD | SPF document out sensor | Transmission photo sensor | L when paper is sensed. |
| 5 | SPPD | SPF document transport sensor | Transmission photo sensor | H when paper is sensed. |
| 6 | SPFD | SPF document set sensor | Transmission photo sensor | L when a document is set. |
| 7 | LHPD | Lens home position sensor | Transmission photo sensor | H at the home position. |
| 8 | PWD | Paper size (large/small) sensor | Transmission photo sensor | L with the large size. |
| 9 | PPD | Paper transport sensor | Transmission photo sensor | L when paper is sensed. |
| F | CPED1 | Tray paper empty sensor | Transmission photo sensor | H when paper is present. |
| G | CPED2 | Option tray paper empty sensor | Transmission photo sensor | H when paper is present. |
| H | CSPPD | Option tray paper path/empty sensor | Transmission photo sensor | H when paper is sensed. |
| I | CSDSW | Option tray paper feed cover open/close sensor | Transmission photo sensor | L when the cover is open. |
| J | PID (MFD1) | Paper sensor for Manual paper feed unit (only single Manual Paper feed unit) | Transmission photo sensor | L when the cover is open. |
