Operation Summary

This manual covers the setup and operation of the Siemens CCBS1337-LP Day-Night Camera. Key functions include:

  • Installation: Connecting power and video outputs, and adjusting the back focus.
  • Day/Night (D/N) Modes: AUTO, MONO, COLOR, MANUAL for various lighting conditions.
  • Image Settings: Adjusting exposure, shutter speed, gain, white balance, gamma, and aperture for optimal picture quality.
  • Advanced Features: Mirroring, privacy zones, backlight compensation (BLC), and alarm functions.
  • Remote Control: Setting up communication protocols, addresses, and baud rates for remote operation.

Refer to specific sections for detailed instructions on each function.

Troubleshooting and error codes

Symptom Possible Cause Solution
No image Camera not powered on Check power connection and supply.
Image is noisy Low light conditions Increase gain or use IR illumination.
Color is inaccurate Incorrect white balance setting Adjust white balance or use AUTO mode.
