Warranty Information
Unauthorized modifications may void your equipment warranty.
- Read instructions carefully before connecting and operating the camera.
- Installation by authorized personnel only, according to local safety regulations.
- Operate the camera with the designated voltage.
- Follow safety instructions and heed all warnings.
- Never use the camera for purposes other than designated.
- Repairs and adjustments by authorized personnel only.
- Disconnect power if liquids or objects enter the housing.
- Equipment complies with limits for Class B digital devices, designed to provide reasonable protection against interference.
- May generate, use, and radiate radio frequency energy; improper installation may cause interference.
- Modifications not explicitly approved may void warranty.
- Use recommended shielded interface cable.
- Do not expose to rain or moisture; install by qualified service person.
- Connect to a 12 V DC or 24 V AC Class 2 power supply for LP camera models.
Troubleshooting and error codes
| Symptom | Possible Cause | Remedy |
|---|---|---|
| Image is blurry | Focus is not set correctly | Adjust backfocus. (Refer to 6.2.4.8 BACKFOCUS) |
| Image is too dark/bright | Exposure settings are incorrect | Adjust EXPOSURE, SHUTTER, LENS LEVEL, GAIN, APERTURE, or WD LEVEL. |
| Color rendition is poor | White balance is incorrect | Adjust WB MODE. |
| No video output | Cable connection issue or power issue | Check BNC cable connection and power supply. |
| Camera is unresponsive | Power issue or system error | Check power supply. Try resetting to default settings. |
