Manual for optiPoint 500

Service Concept

Faulty terminals and adaptors can be debugged on site by exchanging components/adaptors or replacing individual faulty elements, such as handsets, cords, covering panels, etc.

Safety Information

Setting Up the Equipment: The equipment is set up by the user or service technician. Training or orientation on how to use optiPoint500 device parts is not necessary. A mains socket may be necessary for operating telephones and options, depending on the scope of the configuration. If more telephones are to be added later on, make sure that an adequate number of mains sockets are available for connecting the required local power supply units.

Damage to the Equipment: Only use tools and testers suitable for the job. Do not put devices with external damage into service.

Laying Cables: Lay the power and connection cables in such a way as to avoid accidents (no tripping) and damage to the cables.

Troubleshooting and Replacing Boards

Note the following when replacing boards:

• Service tasks should only be carried out by authorized personnel.
• Always replace boards with original spare parts.
• Always disconnect the system from the power source before replacing boards.
• Always follow the instructions and take the proper precautions when handling boards that contain electrostatically sensitive devices.

Protecting Electrostatically Sensitive Devices (ESD)

• Always put on an earthed wristband before performing any work on PC boards.
• Transport PC boards only in suitable protective packaging.
• When working on PC boards, always ensure that they are placed on a grounded conducting base.
• Always use soldering iron for soldering.
