Parts/Service for EXR-10/XLR-2300
Uploaded: Nov. 21, 2025, 8:41 p.m.
Manual Publish Date: 1993-06-01
Warranty Information
No warranty information is available in this manual.
- Audio Power: Delivers 4 watts per channel into 4 ohms with no more than 1.5% total harmonic distortion.
- Tuner Section: Features SSIR PLL synthesizer tuner with automatic memory for 18 stations (12 FM, 6 AM).
- Cassette Player: Auto-reverse function for continuous playback.
- Power Amplifier: Fader control for 4-speaker systems, with power output options.
- General: Includes a quartz-controlled digital clock.
- Controls: Volume, fader, bass, treble, tuning, balance, preset buttons, eject, power on/off, M.SCAN, A.MEM, and loudness.
- Installation: Requires careful location selection to avoid high temperatures and interference with driving functions.
- Connections: Supports 4 or 2 speaker connections and antenna connection. Negative ground 12V DC operation.
- Disassembly: Procedures for removing the front panel, mechanism deck, and main board are outlined.
- Adjustments: Includes mechanical torque measurements and electrical adjustments for tape section, FM, and AM.
