Parts/Service for NW-S202/S202F/S203F/S205F
Uploaded: Nov. 21, 2025, 8:29 p.m.
Manual Publish Date: 2006-11-01
Warranty Information
This manual does not contain warranty information.
Parts and Controls
1. ■ button
Starts song playback. Pressing again stops playback. If pressed after purchasing or disconnecting USB, playback starts from the first song. Use to confirm menu items.
2. VOL +/- button
Adjusts the volume.
3. DISP/HOME button
Changes display in play/stop mode. Press and hold to display HOME screen. Returns to previous screen or HOME screen.
4. Display
Shows information like album title, artist name, song name, date, time, and menus.
5. Shuttle switch
Rotates to select menu items, skip songs, or fast-forward/rewind. Can be slid to HOLD, Folder control, or Normal mode.
6. USB jack
Connects the player to the computer via USB cable.
7. Headphone jack
Connects headphones.
8. Strap hole
For attaching a strap.
Troubleshooting and error codes
| Error Display | Description |
| "CALIB ERROR! GAP" | Difference between each position is too small. |
| "CALIB ERROR! LIN" | X,Y axis may be twisted. Something like hall element defect. |
| "CALIB ERROR! ???" | Undefined errors. (Such as calibration data write error to NAND.) |
