The BKMW-E3000 is a network interface board for installation in an MSW-2000 series digital videocassette recorder. It enables the VTR to connect to a network to transfer video, audio, and metadata as MXF files. Functions include MXF file transfer, low-resolution MXF Proxy AV file transfer, timecode copying, web server network services, and Windows application network services. It also supports FTP/HTTP file transfer via the e-VTR control panel, e-monitor functions, network data rate limitations, automatic IP address acquisition, network operation using host names, and file jump functionality. Automatic MXF file creation from tape or memory label information is also supported. User registration allows for up to 5 users with different privilege levels. Setup menu settings can be backed up to a computer via the network. SNMP functions allow for network device monitoring. External server linking for metadata and automatic file-system data operations with an external server are also featured.

Troubleshooting and error codes

Problem	Possible Cause	Solution
The network indicator light is not lit.	The e-VTR is not connected to the network.	Check the network cable connection and the network settings.
FTP connection is not possible.	The firewall is blocking FTP traffic.	Configure the firewall to allow FTP traffic.
Files cannot be transferred.	Incorrect server settings (IP address, username, password, path).	Verify and correct the server settings in the MXF D10 Transfer Destination or MXF Proxy AV Transfer Destination pages.
e-VTR Manager does not connect to the e-VTR.	Incorrect IP address or hostname in Network Device Register.	Verify the IP address or hostname of the e-VTR and update it in the Network Device Register.
Error messages are displayed.	Refer to the Error Logger Page (page 41) for details on the error messages.	Consult the Error Logger Page for specific error codes and their descriptions.
