Manual for SSM-721AMR

Operation

When you turn the ignition key to the accessory or ON position, the power is supplied to the monitor and the monitor becomes standby condition.

1. Depress the POWER switch ( ♫ ON). The picture appears on the monitor. To turn off the picture, press it again to release (STD BY). The monitor becomes standby condition.
2. Select the camera to be monitored by pressing the INPUT button. To select the camera connected to the CAMERA A connector, depress the button ( A). To select the camera connected to the CAMERA B connector, press the button to release (B).
3. Adjust the VOLUME control.
4. Adjust the picture contrast and brightness.

DAY/NIGHT select switch: Normally keep this switch released ( DAY). When you view the picture at night or in a tunnel, etc., depress the switch to make the picture less bright (NIGHT). The picture will be easy to view even in a dark place.
