Manual for Professional 100HD,Professional 90HD,Professional 80HD

How to use the press iron

1. Open the appliance using the security lock and lifting the handle.
2. Lift the handle further to fix the heated sheet in the biggest open angle.
3. To close, move the handle down; pressure increases automatically, and steam is produced.
4. Always hold the handle while opening, as the iron opens automatically.
5. Maximize opening by lifting the handle up; the steam sheet is wide enough to be used as an ordinary ironing board.
6. Close the press by moving the handle down.

Preparation

1. Plug in the iron and connect it to the outlet, ensuring earth-connection.
2. Turn the appliance on using the ON/OFF key.
3. The red light ring indicates warming up and steam generator working.
4. Temperature rises to the selected degree and stops.
5. Select the appropriate temperature setting based on the cloth type using the international signs.
6. Press the steam key to activate steam production. Steam starts automatically after 5 minutes of pressing ON/OFF.

Pressing

1. Spread material on the iron sheet.
2. Move the heated sheet down by the handle; steam is produced automatically when it reaches a half-closed position.
3. Close the iron for pressing automatically and keep it closed for a few seconds.
4. Open the iron by lifting the handle.
