Manual for TRIO CARE
Uploaded: April 20, 2026, 7:37 p.m.
Warranty Information
The product is guaranteed against defects in material and manufacturing for 24 months from the date of purchase.
Operating the TRIO CARE:
1. Insertion of Batteries: Remove cover, insert 2 AAA batteries respecting polarity, replace cover.
2. Electrode Setup: Remove electrodes from plastic, connect to cables, insert cables into device.
3. Electrode Placement: Peel backing, place on clean, dry, healthy skin, spaced at least 5 cm apart, not touching. Ensure proper alignment.
4. Power On: Press the power button.
5. Program Selection: Press MODE to cycle through TENS, EMS, MASS. Press the program button to select body part or massage type. Press PROGR to cycle through P1, P2, P3 programs.
6. Session Start & Intensity: Press CH to select channel, press the start button to begin. Adjust intensity using +/- buttons (max 25).
1. Insertion of Batteries: Remove cover, insert 2 AAA batteries respecting polarity, replace cover.
2. Electrode Setup: Remove electrodes from plastic, connect to cables, insert cables into device.
3. Electrode Placement: Peel backing, place on clean, dry, healthy skin, spaced at least 5 cm apart, not touching. Ensure proper alignment.
4. Power On: Press the power button.
5. Program Selection: Press MODE to cycle through TENS, EMS, MASS. Press the program button to select body part or massage type. Press PROGR to cycle through P1, P2, P3 programs.
6. Session Start & Intensity: Press CH to select channel, press the start button to begin. Adjust intensity using +/- buttons (max 25).
Troubleshooting and error codes
| PROBLEM | POSSIBLE CAUSES | POSSIBLE SOLUTION |
|---|---|---|
| The unit does not turn on | Batteries are depleted? | Replace batteries. |
| Batteries are not installed correctly? | Insert batteries respecting polarity. | |
| The stimulation is weak or no stimulation is felt | The electrodes are dry or dirty. | Replace with new ones. |
| The electrodes do not adhere well to the skin. | Replace with new ones. | |
| The conductive cable is old, worn, or damaged. | Replace the cable with a new one. | |
| The stimulation is uncomfortable. | The intensity is too high. | Reduce the intensity. |
| The electrodes are too close to each other. | Reposition the electrodes at least 5 cm apart. | |
| Are you using the device according to the manual? | Consult the manual before use. | |
| Intermittent output | Conductive cable | Verify connection is secure. Insert cable firmly. Lower intensity. Rotate cable 90°. If still intermittent, replace cable. If intermittent after replacing cable, contact repair department. |
| Stimulation is ineffective. | Incorrect electrode placement. | Reposition electrodes. |
| Unknown | Contact your doctor. | |
| Using electrodes in the same place all the time. | Reposition electrodes. If pain or discomfort occurs, discontinue use immediately. | |
| The skin turns red and/or feels a stinging pain | The electrodes do not adhere to the skin properly. | Ensure electrodes adhere firmly. |
| The electrodes are dirty. | Clean electrodes as per manual or replace with new ones. | |
| The electrode surface is torn. | Replace with new ones. | |
| The output current stops during therapy. | The electrodes are peeling off the skin. | Turn off device, reposition electrodes or replace with new ones. |
| The conductive cable is disconnected. | Turn off device and connect conductive cable. | |
| Batteries are depleted. | Replace with new batteries. |
