Manual for HD-XA2
Uploaded: Nov. 21, 2025, 6:04 p.m.
Warranty Information
Limited 90-day labor and one-year parts warranty for DAV products purchased and operated in the U.S.A.
- Connect your player to your TV and audio system using the appropriate cables (HDMI, Component, S-Video, or Composite).
- Refer to the "Connecting to a TV" section for detailed connection steps based on your TV's input type.
- Ensure correct MODE switch settings on the player for your chosen connection.
- Load discs into the disc tray and use the PLAY button to start playback.
- Use the remote control for playback functions like play, pause, stop, skip, and menu navigation.
- Explore features like "Internet connection" and "Customizing the function settings" for advanced options.
Troubleshooting and error codes
| Symptom | Remedy |
|---|---|
| No power. | → Is the power plug disconnected? Check the power connection. |
| No picture. | → Is the cable for connecting the player and TV disconnected or not connected properly? Check the connections (page 21 – 22) →Switch the input of the connected TV to the signal from the player. →Check the settings (MODE switch and “Resolution Setting”). ( page 24) →Are both the HDMI OUTPUT jack and the COMPONENT OUTPUT jacks connected simultaneously? Select either connection and make the appropriate setting. (page 21 – 23) |
| No sound. | → Is the audio cable disconnected? (page 22) → Is the volume of the device turned down to the minimum level? Check the volume. →Switch the audio input of the device connected by the audio cable to the input from the player. →Set "Digital Out SPDIF” or “Digital Out HDMI” (page 55) properly in accordance with the connected device and connection procedure. →The volume level is set to the minimum. Adjust the volume. (page 56) →Change the output resolution (page 23) so that sound can be heard. → If using the optical digital output for a Dolby Digital Plus, Dolby TrueHD, DTS-HD or DTS soundtrack, be sure your AV receiver or processor is set to use the input connected to your player and is set to output the respective sounds. |
| Output level of multi channel sound is reduced. | →Set "Speaker Setting" (page 56) to "2ch". |
| Multi channel sound is not output. | →Set "Speaker Setting" (page 56) to "5.1ch”. |
| The disc does not play. | → Make sure the disc type can be played with the player (page 28). → Is the disc dirty or scratched? Check or clean the disc. (page 29) → If the disc is a DVD-RW or DVD-R disc, finalize the disc before attempting to play it with the player. →If the disc includes parent lock support, playback is restricted while the parent lock of the player is set. Cancel Parental Lock (page 59) or change the restriction level. |
| Playback picture has noise. | → If video from the player is watched via a video recorder or on a TV with a built-in video recorder, the copy guard may prevent images from being displayed properly. Be sure to connect the player directly to the TV. |
| The remote control does not work. | →Are the batteries of the remote control dead? Replace the batteries. (page 16) →Make sure the remote control is within range and pointed in the correct direction. |
| Screen freezes and no buttons work. | →Pressing ON/STANDBY button on the player for approximately ten seconds forces the player to turn off. Turn the player off and then on again. |
