Manual for V 64 - 74

Name: Manual for V 64 - 74
Brand: VIMEC
Availability: InStock

Brand: VIMEC

Category: Stairlift

Document Type: Manual

Language: EN

Available Languages: EN , ES

Uploaded: April 20, 2026, 7:39 p.m.

Manual Publish Date: 2007-11-15

Warranty Information

None

Basic Operation: The VIMEC V 64-74 stairlift is designed for transporting persons seated on a wheelchair or special seat with a straight rail at a constant gradient (0°-50°). Users must be self-sufficient and familiar with operation. The stairlift can be operated via control boards on the lift or at the floor using a key. Key safety features include emergency stop buttons, safety bars, and sensor edges. It has intended uses for indoor and outdoor environments and specific user characteristics. Improper uses include overloading or use by unauthorized persons. Emergency manual operation is possible using a handwheel in case of power failure. Always keep access to the platform and master switch unrestricted and never overload the lift.

Troubleshooting and error codes

Problem	Possible causes	Possible remedies
The stairlift does not move in either travel direction.	Control enabling key	Turn the key to ON
	Emergency STOP pressed	Turn the button clockwise through 45°
	Differential security breaker tripped	Press the reset button. If it does not remain in the ON position, call in an authorised VIMEC technician.
	No power supply	Check the power supply; see point 7.5 (operating by hand).
The stairlift moves downward more quickly then cuts out	A safety device has been tripped	Call in an authorised VIMEC technician
The stairlift does not move from either end of the stair	Safety gear tripped	Call in an authorised VIMEC technician
The stairlift does not move in one direction	Overlimits safety device tripped	Call in an authorised VIMEC technician
	Control enabling key	Turn the key to ON
The stairlift hits the stop buffers	Check that there are no obstacles activating the safety devices Fig. 5/c-d-e
		Call in an authorised VIMEC technician
