Warranty Information
WASPcam is not responsible for any collisions, damage, personal injuries, legal repercussions, property damage, or lost/stolen cameras.
Starting Up & Basic Operation:
- Ensure a micro SD card (Class 10, max 32GB) is inserted.
- Press and hold the Power/Mode button for 3 seconds to turn the camera on/off.
- Press the Power/Mode button to cycle through Video, Photo, Playback, and Settings modes.
- In Video Mode, press OK to start/stop recording.
- In Photo Mode, press OK to take a photo.
- In Playback Mode, use Up/Down to scroll through files and OK to play videos.
- Use Up/Down to navigate settings menus and OK to confirm.
Troubleshooting and error codes
| MENU OPTION | SETTINGS |
| Video Resolution | 1080 60FPS / 1080P 30FPS/720P 60FPS / 720P 30FPS |
| Microphone | √ |
| Time-lapse | Off / 0.5s / 1s / 2s / 5s / 10s / 30s / 60s |
| Loop Recording | Off/1minute/3minutes/5minutes |
| Photo Resolution | 16MP/12MP / 8MP / 5MP / 2MP |
| Timer | Off/3s/5s / 10s / 20s (camera will take a photo after selected amount of time) |
| Exposure | +3 +2 +1/ 0 / -1 / -2 / -3 (used to adjust the amount of light let into the camera sensor, use positive setting in bright conditions and negative setting in dark conditions) |
| White Balance | Auto / Sunny / Cloudy / Incandescent Light / Fluorescent Light (Helps balance color in certain lighting to make footage/images look more natural) |
| Driving Mode | √ (Turns on loop recording, auto record, and auto shutdown. Camera turns on and starts recording automatically when connected to the car and the car is on) |
| Light Source Frequency | Auto / 50Hz / 60Hz |
| LED Indicator Light | √ |
| Screen Saver | Off / 10s / 30s / 60s (After a period of inactivity, the camera's LCD will turn off to conserve power. Press OK to wake up the LCD screen) |
| Auto Power Off | Off / 1min / 3mins / 5mins (turns camera off after selected period of inactivity) |
| Date/Time Stamp | □ / √ |
| Language | English, French, Dutch, Portuguese, Polish, Spanish, Italian, Simplified Chinese, Traditional Chinese, Japanese, Russian, Korean, Thai, German, Arabic |
| Date/Time | Allows users to set the current date and time |
| Beep Sound | √ |
| WiFi | □ / √ (Check to enter WiFi mode) |
| Format | YES/NO (formats the SD card and erases all data from the SD card) |
| Restore Defaults | YES / NO (Resets all settings to the default values) |
| Firmware Version | Displays camera's current version (YYYYMMDD VX.X) |
