Brand:
Whirlpool
Category: Ovens
Document Type: Parts/Service
Language: EN
Parts/Service for KR-30
Uploaded: Nov. 21, 2025, 9:22 p.m.
Warranty Information
Provides a one-year full warranty covering defects in materials and workmanship.
Air Flow: Intake air enters at two locations (control panel vent, side mounting rails) and mixes before being pulled through the blower. Air is forced over the cavity vent and exits through a small opening. Air passes through the oven door via natural and forced convection, entering the bottom slots and exiting through top slots or between inner door glass. The convection fan circulates hot air within the cavity.
Self-Clean Cycle: Uses high heat to burn away soil. The cycle is preset for 3-1/2 hours but can be adjusted. The oven heats, then shuts off. The door remains locked for an additional 1/2 hour for cooling. If the latch switch is not satisfied, the cycle terminates.
Troubleshooting and error codes
| Error Code | Description |
|---|---|
| E0 | Control Error |
| E1 | Oven Temp Sensor Error |
| E2 | Door Lock Error |
| E3 | Oven Temp Sensor Error (Upper) |
| E4 | Oven Temp Sensor Error (Lower) |
| E5 | Communication Error |
| E6 | Oven Temp Sensor Error (Lower) |
| E8 | Oven Temp Sensor Error (Upper) |
| F0 | Oven Temp Sensor Error |
| F1 | Oven Temp Sensor Error |
| F2 | Oven Temp Sensor Error |
| F3 | Oven Temp Sensor Error |
| F4 | Oven Temp Sensor Error |
| F5 | Oven Temp Sensor Error |
| F8 | Oven Temp Sensor Error |
