Warranty Information
Whirlpool Corporation assumes no responsibility for any repairs made by unauthorized professionals.
Provides general safety, parts, and information for "Multi-Door Freestanding Refrigerators." Covers safety precautions, product specifications, and features. Details include control panel functions, refrigerator compartment features like adjustable shelves and drawers, freezer compartment details, and dispenser/icemaker specifications. It also outlines diagnostic modes, component testing procedures, and access instructions for various parts of the refrigerator.
Troubleshooting and error codes
| Component | Specifications of all parts 115VAC/60Hz unless noted |
|---|---|
| Cooling | BTUH Variable VEGDGH |
| Compressor | Watt 60 Hz / 98 W |
| Current Lock rotor 3.3 A ± 15% | |
| Current Full load 3.3 A ± 15% | |
| Resistance Run windings 6.4 Ω ± 15% | |
| Resistance Start windings 6.4 Ω ± 8%@77°F | |
| Electric damper control | Inverter 3.6 VDC, red/white = 120 VAC |
| Maximum closing time 16 seconds | |
| Temperature Rating -11°F - 110°F | |
| RPM 3 | |
| Condenser motor | Rotation (facing end opposite shaft) Clockwise |
| RPM 940 | |
| Watt 3.9 W± 15% @115 VAC | |
| NOTE: Fan blade must be fully seated on shaft to achieve proper airflow. | |
| Refrigerator Evaporator fan motor | Rotation (facing end opposite shaft) Clockwise |
| RPM 940 | |
| Watt 2.5± 15% W @12.7 VDC | |
| Freezer Evaporator fan motor | Rotation (facing end opposite shaft) Clockwise |
| RPM 2700 | |
| Watt 5.0± 15% W @12.7 VDC | |
| NOTE: Fan blade must be fully seated on shaft to achieve proper airflow. | |
| Freezer Evaporator Heater | Volt 115VAC |
| Watt 435 ± 5% W | |
| Resistance 30.4± 5% Ω | |
| Controls | |
| Control Board | Volt 120 VAC, 60HZ |
| Thermistor | Temperature Resistance |
| 77°F 2700 Ω ± 5.0% | |
| 36°F 7964 Ω ± 1.0% | |
| 0°F 23,345 Ω ± 2.0% | |
| Type SPDT NO/NC | |
| Light switch | Volt 125/250 VAC |
| Current 8/4 A | |
| Ice & Water | |
| Dual Water Valve | Watts Green side 10 W Red side 35 W |
| Isolation Valve | Watts 20 W (Green) |
| Rotation (facing end opposite shaft) Clockwise | |
| Ice Box Fan | RPM 3500 |
| Watt 3.8 W ± 15% @ 12.7 VDC |
