Manual for CRX-E300

Manual for CRX-E300

Brand: YAMAHA

Category: Audio/Video

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 8:38 p.m.

  • System Control Features: One bus line controls all units. Units are connected in series using monaural mini jacks. Units can be connected in any order.
  • Main System Operation (POWER ON/OFF): Units are connected to the AC outlet in series and switched on/off through the CRX relay. Turning off the CRX power switch turns off power to other units, but turning off other units' power only affects their secondary connection. Units have a backup function to save secondary connection status. Indicators light up simultaneously with CRX power ON, with a 2-second delay if other units are used alone. Power off processing must be completed before turning off the CRX.
  • FUNCTION Selection: Only the selected source will be reproduced. Functions adjust automatically to the source. Function switching is prohibited during recording.
  • TIMER Operation: Supports TIMER PLAY for scheduled reproduction and TIMER REC for scheduled recording.
  • AUTO POWER ON: If connected units are turned off while CRX is on, pressing a reproduction key will automatically turn the power on.

Troubleshooting and error codes

Error Code Status Contents
E-10 PLAY CD fails in the disc data reading state shift.
E-20 SCAN
E-30 PAUSE
E-70 SEARCH
E-11 PLAY CD fails in the reading.
E-21 SCAN
E-31 PAUSE TOC data reading
E-73 LOAD CD fails in the TOC data reading
E-04 LOAD, SEARCH Tracking servo is not effective at the DISC MOTOR SERVO PLL.
E-14 LOAD, SEARCH Disc motor servo PLL is not effective.
E-35 CD fails in FOCUS SEARCH.
E-06 SEARCH, PLAY, PAUSE CD fails in escaping from the LEAD-IN area.
E-47 SEARCH
E-57 STOP The inner limit switch does not operate at the FEED INNER CONTROL.
E-77 LOAD, EJECT
E-18 PLAY CD fails in recovery from the FOCUS OUT.
E-28 SCAN
E-38 PAUSE
E-48 SEARCH
E-68 LOAD
E-AC Close switch does not operate at the TRAY CLOSE CONTROL.
E-AD Open switch does not operate at the TRAY OPEN CONTROL.
MN ERR MN35511 does not give response of SENSE with resetting.
