SETTING THE CLOCK

When the oven is plugged in for the first time, you can set the 24-hour clock. Press the clock/weight button, rotate the time/menu knob to adjust the hour, press to confirm, rotate to adjust the minutes, and press to confirm. During cooking, press the clock/weight button to check the time.

MICROWAVE COOKING

Customize cooking power and time (max 95 minutes). Example: Cook for 5 mins at 60% power. Open door, place food, close. Press power level button 3 times, rotate time/menu knob for time, press start. Power levels range from 100% (P100) down to 0% (P-00).

GRILL

Ideal for thin slices of meat, sausages, chicken, sandwiches, and au gratin dishes (max 95 minutes). Example: Grill for 12 mins. Open door, place food, close. Press grill button, rotate time/menu knob for time, press start. High rack recommended.

MICRO. + GRILL

Combines microwave and grill functions (max 95 minutes). Example: Combi for 25 mins. Open door, place food, close. Press micro.+grill button, rotate time/menu knob for time, press start. Pre-set combinations available (e.g., fish, potatoes).

CONVECTION COOKING

Circulates hot air for browning and crisping (max 95 minutes). Programmable for ten temperatures. Example: Cook at 180°C for 40 mins. Open door, place food, close. Press convection button 3 times, rotate time/menu knob for time, press start.

MICRO. + CONVECTION

Pre-programmed for 200°C convection and microwave. Example: Cook for 24 mins. Open door, place food, close. Press micro.+convection button, rotate time/menu knob for time, press start.

QUICK START

Directly start cooking at 100% for 30 seconds by pressing start/quick start. Press again to add more time.

AUTO COOK

Automatically determines mode and time. Choose from 8 menus. Open door, place food, close. Rotate time/menu knob to select food, press start. Select amount/weight with clock/weight button, press start. Follow on-screen prompts for specific foods.

AUTO DEFROST

Automatically defrosts food. Example: Defrost frozen food for 10 mins. Open door, place food, close. Rotate time/menu knob to A-09, press start. Set time, press start. Turn food during defrosting.

MULTI-STAGE COOKING

Program up to 3 stages. Example: Stage 1: 2m 30s at 40%; Stage 2: 5m grill. Follow specific button presses for each stage.

CHILD SAFETY LOCK

Prevents unsupervised operation. Enabled automatically after 1 minute of inactivity. Open door to cancel.

PAUSE

Press stop/cancel to pause, press start/quick start to resume.

Problem	Check if . . .
The microwave appliance is not working properly?	• The fuses in the fuse box are working. • There has not been a power outage. • If the fuses continue to blow, please contact a qualified electrician.
The microwave mode is not working?	• The door is properly closed. • The door seals and their surfaces are clean. • The START button has been pressed.
The turntable is not turning?	• The turntable support is correctly connected to the drive. • The ovenware does not extend beyond the turntable. • Food does not extend beyond the edge of the turntable preventing it from rotating. • There is nothing in the well beneath the turntable.
The microwave will not switch off?	• Isolate the appliance from the fuse box.
The interior light is not working?	• Call an authorised ELECTROLUX service agent.
The food is taking longer to heat through and cook than before?	• Set a longer cooking time (double quantity = nearly double time) or • If the food is colder than usual, rotate or turn from time to time or • Set a higher power setting.

Manual for ZMSN4C
