Brand: ZANUSSI
Category: Oven
Document Type: Manual
Language: EN
Manual for ZOHNX3K1
Uploaded: Nov. 21, 2025, 6:32 p.m.
Warranty Information
Refer to the manufacturer for specific warranty details.
- Initial Cleaning: Remove accessories, clean oven and accessories with a soft cloth, warm water, and mild detergent.
- Initial Preheating: Preheat the empty oven to maximum temperature for 1 hour, then for 15 minutes. Ensure ventilation.
- Daily Use: Set heating function and temperature using retractable knobs. The lamp turns on when the oven operates. Turn the function knob to 'Off' to turn off the oven.
- Heating Functions: Includes 'Off position', 'Light', 'True Fan Cooking' (for baking and drying), 'Moist Fan Baking' (energy saving), 'Defrost', 'Grill', 'Fast Grilling', and 'Turbo Grilling'.
- Clock Functions: Set Time of Day, Duration, End Time, Time Delay, and Minute Minder.
- Using Accessories: Insert wire shelves, deep pans, and trivets according to instructions.
- Additional Functions: Cooling fan operates automatically to cool surfaces. Safety thermostat prevents overheating.
- Hints and Tips: Recommendations for cooking cakes, meat, fish, and general cooking times.
Troubleshooting and error codes
| Description | Possible cause | Remedy |
|---|---|---|
| The oven does not turn on or does not heat up | The oven is deactivated. | Activate the oven. |
| The oven does not turn on or does not heat up | The clock is not set. | Set the clock. |
| The oven does not turn on or does not heat up | The necessary settings are not set. | Make sure that the settings are correct. |
| The oven does not turn on or does not heat up | The fuse is blown. | Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. |
| Problems with components | The lamp does not operate. | The lamp is defective. Replace the lamp. |
| Problems with components | The door gasket is damaged. | Do not use the oven. Contact an Authorised Service Centre. |
| Display shows: | The display shows "12.00". | There was a power cut. Set the clock. |
| Problems with cleaning procedure | Steam and condensation settle on the food and in the cavity of the oven. | You left the dish in the oven for too long. Do not leave the dishes in the oven for longer than 15 - 20 minutes after the cooking process ends. |
