Manual for TC 180

Manual for TC 180

Brand: ZANUSSI

Category: Tumble Dryer

Document Type: Manual

Language: EN

Uploaded: Nov. 21, 2025, 7:35 p.m.

Warranty Information

12-month guarantee covering faulty workmanship or materials, subject to correct installation and use.

Using your appliance

  1. Check electrical connection.
  2. Open door, check fluff and coarse filters are clean and in place.
  3. Ensure water tank is empty and correctly inserted.
  4. Load laundry loosely, do not mix synthetics with natural materials.
  5. Select drying time and temperature using the timer knob (Cotton or Synthetics scale).
  6. Close door to start. Avoid opening door during cycle.

Maintenance and cleaning

Filters: Clean fluff and coarse filters before or after each load. Never start without a clean, correctly placed fluff filter.

Condenser: Clean occasionally by opening the door, removing fluff filter, releasing condenser, soaking in water, rinsing, and drying before reinserting.

Water tank: Empty when the warning light comes on, or before/after each load.

Troubleshooting and error codes

Fault Check
The machine will not start.
  • Is the door closed properly?
  • Is there power to the machine?
  • Has the fuse blown? (Start with fuse in electrical plug).
  • Have you set the program/timer knob properly?
  • Is the water tank full?
The load is not drying properly, or is taking long time to dry.
  • Was the time set not long enough?
  • Is the load too large? (Cotton max 3,4 kg, Synthetics max 1,5 kg)
  • Is the fluff filter clogged?
  • Is the condenser clogged?
  • Was the load not spun enough in the washing machine?
  • Have you been using the "Synthetics" setting (on the timer) (lower drying temperature)?
  • Is the temperature in the room too high? (Must not exceed +35° C).
The area around the dryer is hot.
  • Is the room too small? (Improve the room ventilation, open a door or window or choose another site for the dryer).
