Manual for ZDC47200W
Uploaded: Nov. 21, 2025, 9:20 p.m.
- Switching on: Turn the programme selector to any programme.
- Loading: Open door, load laundry, close securely.
- Programme selection: Turn the programme selector dial. Start/Pause button light flashes.
- Additional functions: Select DELICATE or TEXTILE options if needed.
- Starting: Press the Start/Pause button. The light stops flashing.
- Indicator lights: Show drying phase, end/anti-crease, tank full, filter clean needed, condenser clean needed.
- At the end: Programme includes a 10-minute cooling phase, then an anti-crease phase (max. 30 min). Remove laundry promptly.
- After each use: Clean filters and empty the water reservoir.
Troubleshooting and error codes
| Problem1) | Possible cause | Remedy |
|---|---|---|
| Dryer does not work. | Dryer not connected to mains supply. | Plug in at mains socket. Check fuse in fuse box (domestic installation). |
| Loading door opened. | Close loading door | |
| The START PAUSE button not pressed. | Press the START PAUSE button. | |
| Unsatisfactory drying results. | Incorrect programme set. | Set suitable programme. 2) |
| Fluff filters clogged. | Clean fluff filters. 3) | |
| Heat exchanger clogged. | Clean heat exchanger. 3) | |
| Max. loading exceeded. | Respect max. loading volume. | |
| Covered ventilation grill. | Uncover ventilation grill in base area. | |
| Residue inside the drum. | Clean the drum inside. | |
| To little free space around the appliance | Ensure min. 5cm free space around the appli-ance | |
| Loading door does not close | Filters not locked in place. | Install fine filter and/or snap course filter into place. |
| Programme in- active | Full water reservoir. | Empty water reservoir3) , press START PAUSE button. |
| Drying cycle to short | Small laundry volume./Too dry laundry for selected programme. | Select time programme or higher drying level (e.g. EXTRA DRY ). |
| Fluff filters clogged. | Clean fluff filters. | |
| To high loading volume. | Respect max. loading volume. | |
| Drying cycle to long 4) | Laundry insufficiently spun. | Spun adequately the laundry. |
| Particularly high room temperature - no machine fault. | Lower the room temperature if possible. |
