Daily use

Switching machine on

Turn the programme selector to any programme. The machine switches on.

Door opening and laundry loading

  1. Open the door.
  2. Load your laundry (do not force it in).
    Caution! Do not jam laundry in between the loading door and rubber seal.
  3. Close loading door securely. Lock must audibly lock.

Selecting the programme

Turn the programme selector dial to the required programme. The light START/PAUSE starts to flash.

Drying cycle complete / removing laundry

Once the drying cycle is complete, the lights ANTI-CREASE-END and FILTER are on. If the buzzer is active, an acoustic signal sounds intermittently for about one minute.

The drying cycles are automatically followed by an anti-crease phase which lasts around 30 minutes. The drum rotates at intervals during this phase. This keeps the laundry loose and free of creases. The laundry can be removed at any time during the anti-crease phase.

  1. Open door.
  2. Clean the filter.
  3. Remove laundry.
  4. Turn the programme selector to "O" - OFF.
  5. Close the door.

Troubleshooting and error codes

Problem Possible cause Remedy
Dryer does not work. Mains plug is not plugged in or fuse is not working correctly. Plug in at mains socket. Check fuse in fuse box (domestic installation).
Loading door is open. Close loading door.
Have you pressed the START PAUSE button? Press the START PAUSE button again.
Drying results unsatisfactory. Wrong programme selected. Select a different programme the next time you dry (see "Programme chart" chapter).
Fluff filter clogged. Clean fluff filter.
Overloading of laundry. Observe recommended loading volumes.
Ventilation slots covered up. Uncover ventilation slots.
Residue on inside surface of drum or drum ribs. Clean inside surface of drum and drum ribs.
Loading door does not close. Filter not in place2). Install filter into place2).
Drying cycle ends shortly after programme starts. Not enough washing loaded or washing loaded is too dry for selected programme. Select time programme or higher drying level (e.g. EXTRA DRY instead of CUPBOARD DRY ).
Drying cycle lasts an unusually long time. Note: After around 5 hours the drying cycle ends automatically. Filter clogged. Clean filter.
Load volume too big. Reduce load volume.
Laundry insufficiently spun. Laundry must be adequately spun.
