Warranty Information

Refer to the warranty information provided separately with your appliance.

Loading the laundry:

Connect the appliance and open the door. Place laundry in the drum, one item at a time, shaking it out. Close the door, ensuring no items are caught. Check laundry is not dripping wet. Ensure garments are suitable for machine drying, following label instructions. Close pillowcases, fasteners, zips, and tie belts. Sort laundry by type and drying requirement. Avoid over-drying to prevent creasing and save energy. Do not dry dark clothes with light, fluffy items to prevent fluff transfer. Ensure laundry is well spun. Easy-care items should be briefly pre-spun. Knitted textiles may shrink; avoid overdrying. Starched items can be used, selecting the 'iron dry' program. Use fabric softener or a specific tumble dryer conditioner to avoid static. Remove laundry promptly. For items still damp, set a brief post-drying time (at least 30 minutes). Ensure laundry is no more than half full for synthetics and one-third full for delicates and woollens. Try to load to maximum capacity as small loads are uneconomical.

Selecting the programme:

Turn the programme selector dial to the desired programme; the Start/Pause light will flash. The dial is divided into sections for Cottons, Synthetics, and Special programs. Electronically controlled programs use probes to detect dampness. Time-controlled drying is also available. Programme option buttons (Delicate, Delay, Alarme, Long-Anticrease) can be selected before pressing Start/Pause. The 'Delicate' option is for loads up to 3kg. The 'Long-Anticrease' option adds a 90-minute anti-crease phase after the drying cycle. The 'Delay Start' button allows for a 3, 6, or 9-hour delay. Press Start/Pause to begin the cycle. The drying, end of program, and anti-crease phase indicator lights will illuminate as the cycle progresses. At the end, a cooling phase occurs. Remove laundry promptly or the dryer will enter a longer anti-crease phase and then stop. Turn the dial to 'O' to switch off. Clean filters and empty the water reservoir after each use.

Troubleshooting and error codes

MalfunctionPossible causeSolution
Dryer does not work.• Mains plug is not plugged in or fuse is not working correctly.
• Loading door is open.
• Have you pressed the START/PAUSE ▷II button?
• Plug in at mains socket. Check fuse in fuse box (domestic installation).
• Close loading door.
• Press the START/PAUSE ▷II button again.
Drying results unsatisfactory.• Wrong programme selected.
• Lint filter clogged.
• Heat exchanger clogged with lint.
• Incorrect volume of laundry.
• Ventilation slots in base area covered up.
• Residue on inside surface of drum or drum ribs.
• Conductance of water at installation site differs from standard setting of machine.
• Select a different programme the next time you dry.
• Clean lint filter.
• Clean heat exchanger.
• Observe recommended loading volumes.
• Uncover ventilation slots in base area.
• Clean inside surface of drum and drum ribs
• Re-programme standard setting for degree of drying.
Loading door does not close.• Fine strainer not in place and/or large mesh filter not locked in place.• Install fine strainer and/or snap large mesh filter into place.
When pressing a button, the corresponding button flashes several times.• Washing protection. After the start of the programme, the option can no longer be set.• Turn the programme knob to “0” Set the programme again
Drying cycle ends shortly after programme starts. END → light illuminated.• Not enough washing loaded or washing loaded is too dry for selected programme.• Select time programme or higher drying level (e.g. EXTRA DRY instead of CUPBOARD ⌂).
Programme inactive, Water reservoir full light illuminated.• Condensate tank is full.• Empty condensate tank, then start programme with START/PAUSE ▷II button.
Drying cycle lasts an unusually long time.• Lint filter clogged.
• Heat exchanger clogged with lint.
• DELICATE button pressed and load volume too big.
• Load volume too big.
• Laundry insufficiently predrained.
• Clean lint filter
• Clean heat exchanger.
• DELICATE is only suitable for use with loads of up to 3 kg!
• Reduce load volume.
• Laundry must be adequately pre-drained.
