Manual for PowerFlex 525 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:57 p.m.
Manual Publish Date: 2013-02-01
Warranty Summary
No warranty information is provided in this user manual.
Quick Start Guide:
- Review safety precautions.
- Verify PowerFlex drive installation.
- Connect drive to EtherNet/IP network (Ethernet cable).
- Apply power to the drive and verify status indicators.
- Configure adapter for application (IP address, data rate, I/O, etc.).
- Configure controller to communicate with adapter.
- Create ladder logic program for control and monitoring.
Refer to the manual for detailed steps and parameter settings.
Troubleshooting and error codes
| Item | Name | State | Description |
|---|---|---|---|
| 1 | ENET | Off | Adapter is not connected to the network. |
| Steady | Adapter is connected to the network and drive is controlled through Ethernet. | ||
| Flashing | Adapter is connected to the network but drive is not controlled through Ethernet. | ||
| 2 | LINK | Off | Adapter is not connected to the network |
| Steady | Adapter is connected to the network but not transmitting data. | ||
| Flashing | Adapter is connected to the network and transmitting data. | ||
| 3 | FAULT | Flashing Red | Indicates drive is faulted. |
Troubleshooting and error codes
| Item | Name | State | Description |
|---|---|---|---|
| 1 | ENET | Off | Adapter is not connected to the network. |
| Steady | Adapter is connected to the network and drive is controlled through Ethernet. | ||
| Flashing | Adapter is connected to the network but drive is not controlled through Ethernet. | ||
| 2 | LINK | Off | Adapter is not connected to the network |
| Steady | Adapter is connected to the network but not transmitting data. | ||
| Flashing | Adapter is connected to the network and transmitting data. | ||
| 3 | FAULT | Flashing Red | Indicates drive is faulted. |
