Manual for PowerFlex 525 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:45 p.m.
Manual Publish Date: 2013-02-01
Warranty Summary
No warranty information found in this manual.
This manual provides basic information for installing, starting up, and troubleshooting the PowerFlex 525 Adjustable Frequency AC Drive. Key operations include initial setup, navigating the control interface using display and control keys, parameter viewing and editing, and utilizing programming tools for configuration. The manual emphasizes safety precautions throughout the installation and operation process.
Troubleshooting and error codes
| No. | Fault | Type(1) | Description | Action |
|---|---|---|---|---|
| F000 | No Fault | – | No fault present. | – |
| F002 | Auxiliary Input | 1 | External trip (Auxiliary) input. | • Check remote wiring. • Verify communications programming for intentional fault. |
| F003 | Power Loss | 2 | Single phase operation detected with excessive load. | • Monitor the incoming AC line for low voltage or line power interruption. • Check input fuses. • Reduce load. |
Troubleshooting and error codes
| No. | Fault | Type(1) | Description | Action |
|---|---|---|---|---|
| F000 | No Fault | – | No fault present. | – |
| F002 | Auxiliary Input | 1 | External trip (Auxiliary) input. | • Check remote wiring. • Verify communications programming for intentional fault. |
| F003 | Power Loss | 2 | Single phase operation detected with excessive load. | • Monitor the incoming AC line for low voltage or line power interruption. • Check input fuses. • Reduce load. |
