Manual for MVP - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:56 p.m.
Manual Publish Date: 2007-06-01
Warranty Summary
AllStar Pro, LLC warrants the MVP Series drive train to be free from defects for 20 years and other parts for 2 years from purchase date.
Basic Operation:
- FULLY OPEN: Push button/radio control: Door moves DOWNWARD.
- FULLY CLOSED: Push button/radio control: Door moves UPWARD.
- MOVING UPWARD: Push button: Door STOPS. Next push: Door moves DOWNWARD.
- MOVING UPWARD: Radio control: Door STOPS. Next push: Door RESUMES UPWARD.
- MOVING DOWNWARD: Push button/radio control: Door STOPS, PAUSES, then moves UPWARD.
- MOVING DOWNWARD (reaching limit): Lamp blinks off briefly, then remains on for 4 minutes 30 seconds.
- MOVING UPWARD (reaching limit): Lamp remains on for 4 minutes 30 seconds.
Troubleshooting and error codes
| DIAGNOSTIC CONDITION | RED LED | GREEN LED |
|---|---|---|
| Normal Operation | OFF | OFF |
| Learn Mode | ON | OFF |
| Memory Full | OFF | ON FOR 25 SEC, AUTO OFF |
| Decode RF Signal | SHORT FAST BLINK | OFF |
| Shorted Push Button or Wire to Button | OFF | ON |
| Photobeam Obstruction | OFF | FAST BLINK |
| Contact Reverse | SLOW BLINK | OFF |
| Stuck Relay | SLOW BLINK | OFF |
| Stuck Open Limit | OFF | SLOW BLINK |
Troubleshooting and error codes
| DIAGNOSTIC CONDITION | RED LED | GREEN LED |
|---|---|---|
| Normal Operation | OFF | OFF |
| Learn Mode | ON | OFF |
| Memory Full | OFF | ON FOR 25 SEC, AUTO OFF |
| Decode RF Signal | SHORT FAST BLINK | OFF |
| Shorted Push Button or Wire to Button | OFF | ON |
| Photobeam Obstruction | OFF | FAST BLINK |
| Contact Reverse | SLOW BLINK | OFF |
| Stuck Relay | SLOW BLINK | OFF |
| Stuck Open Limit | OFF | SLOW BLINK |
