Manual for SW300 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:49 p.m.
Manual Publish Date: 2014-10-28
Warranty Summary
None
The Besam SW300/SW150 swing door operator utilizes a DC motor and gear system for automated door operation. It is designed for surface-mounted applications and comes in two versions: SW300 for fire doors with an adjustable mechanical spring, and SW150 for non-fire doors without a spring.
Opening: Upon receiving a signal, the door opens at an adjustable speed, slowing down before reaching full open position. The open position is motor-held.
Closing: After a set hold-open time, the door closes automatically using spring force and motor, slowing down for latch check before fully closing. The door remains closed by spring power or extended closing torque.
Control: Operation modes are selectable via a control switch (OFF/AUTO/OPEN).
Troubleshooting and error codes
| Fault | Possible reasons why | Remedies/Explanations |
|---|---|---|
| The door does not open The motor does not start | Control switch is set to OFF | Change the setting of the control switch |
| The door does not open The motor does not start | Electrical power is missing | Check the electrical power power switch |
| The door does not open The motor does not start | Activation unit does not function | Strap impulse inputs |
| The door does not open The motor does not start | Presence detection is activated | Check that there are no objects in the detection zone |
| The door does not open The motor does not start | KILL activated | Deactivate KILL |
| The motor starts but the door does not open | Mechanical lock is locked | Unlock the lock |
| The motor starts but the door does not open | Something jammed beneath the door | Remove object |
| The motor starts but the door does not open | Electric striking plate is binding | Select lock release Adjust striking |
| The motor starts but the door does not open | Arm system has come loose | Use the tool and the nib, put the door in required open position. Tighten the arm system. |
| The door does not close | Control switch is set to HOLD OPEN | Change the setting of the OFF/AUTO/OPEN switch |
| The door does not close | Presence impulse is activated | Remove objects in the detection zone |
| The door does not close | Something jammed beneath the door | Remove object |
