Manual for BTV3TB - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:56 p.m.
Warranty Summary
No warranty information is mentioned in this manual.
Basic Operations Summary:
- First Time Setup: Initial installation process including language and country selection, and automatic channel tuning.
- Channel Navigation: Using CH+/CH- buttons on the device or remote control, and accessing channel lists via the remote.
- EPG (Electronic Program Guide): Accessing program schedules, setting reminders, and scheduling recordings.
- Recording: Recording current or scheduled programs to a USB drive (FAT32 format).
- Media Centre: Playing video, audio, and photo files from a connected USB drive.
- Menu Settings: Customizing preferences, settings, AV output, and managing channels.
Troubleshooting and error codes
| Problem | Potential Reasons | What to do |
|---|---|---|
| No picture | Power isn't connected | Connect the power |
| The power switch is not on | Switch on the power | |
| Screen shows "No Signal" | DVB-T cable not connected | Plug in the DVB-T cable |
| Aerial cable is faulty | Check aerial cable and connections | |
| No sound from speaker | No or incorrect connection with audio cable | Connect the audio cable correctly |
| Sound on mute | Turn off mute function | |
| Only sound, no image on the screen | Resolution not supported by TV set. | Press V-FORMAT button to change resolution. |
| No or incorrect connection with AV cable | Make sure cables are connected correctly | |
| The program is a radio program | Press <TV/RADIO> key to shift into TV mode | |
| Remote Control is not responding | The battery is exhausted | Change battery |
| Remote Control is not facing or close enough to the Set Top Box | Adjust the position of the Remote Control and move closer to the unit | |
| Picture is breaking up | The signal is too weak | Check aerial cable and connections |
