Warranty Summary

Clore Automotive warrants the BOOSTER PAC ES5000 for one year against defects in material or workmanship.
Download Manual

Emergency Jump Starter:

  • Use in well-ventilated area.
  • Shield eyes, wear protective eyewear.
  • Review manuals.
  • Turn ignition off.
  • Clamp positive (red +) to positive terminal.
  • Clamp negative (black -) to vehicle frame.
  • Ensure cables are clear of moving parts.
  • Stay clear of batteries.
  • Start vehicle.
  • Disconnect negative (-) clamp first.
  • Disconnect positive (+) clamp.

Alternative Power Supply:

  • Plug power extension cord from Booster PAC to vehicle's 12V outlet to save vehicle memory during battery replacement.
  • Ensure the chosen outlet is live when vehicle is OFF.

Troubleshooting and error codes

Problem Answer
1 or 2 red lights on, charger plugged in for 24 hours, no change in lights. Check charger to see if it is charging. Charger should be warm.
Charger works well but still no change in status of lights (yellow light is on). Possible defective battery or faulty breaker. Test with 12V device. If it works, breaker is OK, battery is the problem.
All lights on when charger plugged in, but no lights when unplugged and test button pressed. Your Booster PAC has a defective battery which must be replaced.
Booster PAC fully charged but has no power. Check wire where it meets the jaw on the Booster PAC clamp. Ensure well crimped.
Clicking sound from inside when using 12V outlet. Accessory drawing too many amps, causing circuit breaker to cycle. May be overload condition or short circuit in accessory.
