Brand: BRIGGS & STRATTON
Category: Lawn Mower
Manual Type:
Language:
Manual for 500 SERIES - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:49 p.m.
Manual Publish Date: 2011-01-01
Warranty Summary
This lawnmower is guaranteed against faulty parts or manufacturing defects for domestic use for 2 years from purchase date.
Basic Operation Summary:
- Check engine oil and fuel levels before each use.
- Ensure the lawnmower is on a firm, level surface.
- Before checking underneath, remove the spark plug cap.
- Inspect the underside for debris.
- Verify the HT lead is correctly fitted to the spark plug.
- For 400 Series engines, set the throttle to the FAST position.
- Prime the engine 3 to 10 times by pressing the primer bulb.
- Hold the Operator Presence Control (OPC) lever against the handle during starting and operation.
- Pull the cord to start the engine.
Troubleshooting and error codes
| Problem | Likely Cause | Solution |
|---|---|---|
| Engine is difficult to start | Spark plug disconnected | Check the spark plug cap is firmly fitted (see A) |
| Dirty spark plug or incorrect gap | Check the spark plug (see A) | |
| No fuel | Check and top up (see B) | |
| Stale fuel or build-ups in fuel tank | Drain old fuel, re-fill with fresh fuel (see B) | |
| OPC Cable has stretched | Adjust or replace (see C) |
Troubleshooting and error codes
| Problem | Likely Cause | Solution |
|---|---|---|
| Engine is difficult to start | Spark plug disconnected | Check the spark plug cap is firmly fitted (see A) |
| Dirty spark plug or incorrect gap | Check the spark plug (see A) | |
| No fuel | Check and top up (see B) | |
| Stale fuel or build-ups in fuel tank | Drain old fuel, re-fill with fresh fuel (see B) | |
| OPC Cable has stretched | Adjust or replace (see C) |
