Manual for 344652 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 3:36 a.m.
Warranty Summary
For warranty information, refer to the documentation downloadable from the website.
Key Operation:
- Keys illuminate and beep when pressed (can be deactivated).
- 1. Loudspeaker: For audio output.
- 2. 5" Display: Visual interface.
- 3. Bell exclusion LED: Indicates when the ringer is off.
- 4. Door lock release touch key: Opens the door (safe lock function available).
- 5. Entrance panel/scrolling activation touch key: Activates external panel view.
- 6. Tactile guides: For visually impaired users.
- 7. Communication enabling key: Starts/ends communication.
- 8. Microphone: For audio input.
- 9. Favourites/staircase light control touch key: Controls lights or favourite functions.
- 10. Communication enabling key: Starts/ends communication.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Device not working | Power supply issue | Check power connection |
| No audio | Volume too low or muted | Adjust volume settings |
| No video | Incorrect connection or signal issue | Check video connections |
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Device not working | Power supply issue | Check power connection |
| No audio | Volume too low or muted | Adjust volume settings |
| No video | Incorrect connection or signal issue | Check video connections |
