Brand: Carrier
Category: HVAC Controller
Manual Type:
Language:
Manual for WEATHERMASTER 50HJQ004-016
Uploaded: April 8, 2025, 1:57 p.m.
Manual Publish Date: 2004-01-01
Warranty Summary
Warranty information is not provided in this product data manual.
Cooling (without economizer): When thermostat calls for cooling, indoor fan, reversing valve, and compressor are energized. Outdoor fan runs continuously during cooling.
Heating (without economizer): When thermostat calls for heating, indoor fan, outdoor fan, and compressor are energized and reversing valves are deenergized. If space temperature drops further, electric heaters are energized.
Automatic Changeover: System automatically switches between heating and cooling based on space temperature changes relative to set points.
Continuous Air Circulation: Indoor fan can run continuously by setting fan switch to ON.
