Warranty Summary

The CENTRAL PNEUMATIC 62380 Air Compressor is warranted to be free from defects in material and workmanship for 90 days from the date of purchase.
Download Manual
  1. Turn the Power Switch OFF.
  2. Close the Drain Valve.
  3. Close the in-line Shutoff Valve.
  4. Plug in the Power Cord into a grounded 120 VAC outlet.
  5. Turn the Power Switch ON.
  6. Allow the Air Compressor to build up pressure until it cycles off.
  7. Adjust the Regulator Knob to set the desired air pressure.
  8. Connect the air tool to the air hose.
  9. Open the in-line Shutoff Valve.
  10. Use the air tool as needed.
  11. After use, turn the Power Switch OFF.
  12. Unplug the Air Compressor.
  13. Close the in-line Shutoff Valve.
  14. Bleed air from the tool and disconnect the tool.
  15. Drain moisture from the tank.
  16. Clean and store indoors.

Troubleshooting and error codes

Problem Possible Causes Likely Solutions
Compressor does not start or restart 1. Tank(s) already pressurized.
2. Power cord not plugged in properly.
3. Incorrect power supply.
4. No power at outlet.
5. Thermal overload switch tripped.
6. Building power supply circuit tripped or blown fuse.
7. Cord wire size is too small or cord is too long to properly power compressor.
8. Compressor needs service.		 1. Check pressure gauges. If pressurized, no problem. Compressor will start when needed.
2. Check that cord is plugged in securely.
3. Check that circuit matches compressor requirements.
4. Reset circuit breaker, or have outlet serviced by a qualified technician.
5. Turn off Compressor and wait for it to cool down. Press reset button. Resume operation.
6. Reset circuit or replace fuse. Check for low voltage conditions. It may be necessary to disconnect other electrical appliances from the circuit or move the compressor to its own circuit.
7. Use larger diameter or shorter extension cord or eliminate extension cord. See Recommended Wire Gauge for Extension Cords in Safety section.
8. Have unit inspected by a qualified technician.
Compressor builds pressure too slowly 1. Incorrect power supply.
2. Working environment too cold.
3. Safety valve leaking.
4. Loose fittings.		 1. Check that circuit matches compressor requirements.
2. Move compressor to a warmer location.
3. Listen for air leaking from valve. If leaking, replace with identical valve with same rating. DO NOT SEAL OR TAMPER WITH SAFETY VALVE.
4. Reduce air pressure, then check all fittings with a soap solution for air leaks and tighten as needed. Do not overtighten.
Compressor not building enough air pressure 1. Air filters need cleaning/replacing.
2. Check Valve needs service.
3. Compressor not large enough for job.
4. Loose fittings.
5. Hose or hose connections too narrow.
6. High altitude reducing air output.		 1. Check inlet and outlet filters. Clean and/or replace as needed.
2. Have technician clean or replace, as needed.
3. Check if accessory CFM is met by Compressor. If Compressor cannot supply enough air flow (CFM), you need a larger Compressor.
4. Reduce air pressure, then check all fittings with a soap solution for air leaks and tighten as needed. Do not overtighten.
5. Replace with wider hose and/or hose connections.
6. Higher altitudes require compressors with greater output.
Fuses blow/ circuit breaker trips repeatedly 1. Incorrect size fuse, circuit overload.
2. Wrong gauge wire or length of extension cord.
3. Defective check valve or under loader.		 1. Check for proper fuse, use time-delay fuse, disconnect other electrical appliances from circuit or operate compressor on its own branch circuit.
2. Check for proper gauge wire and cord length.
3. Take compressor to service center.
