Warranty Summary

Repair should be done by authorized service personnel only.

\n Before Use:\n

Check the machine for damage and completeness.
Install the machine respecting safety warnings (space around, away from water sources, etc.).
Connect to a earthed socket with correct voltage.
Set up the machine: fill water tank, perform initial water delivery.

\n Turning on the machine:\n

Ensure main switch on back is ON.
Press the power button to turn on.
Machine performs preheat and rinse cycle.
Machine is ready after cycle completion.

Troubleshooting and error codes

\n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n

LIGHTS DISPLAYED	POSSIBLE CAUSE	REMEDY
FLASHING	Insufficient water in the tank (A17)	Fill the tank with water and/or insert it correctly, pushing it as far as it will go until it clicks into place.
FLASHING	The tank (A17) is missing or not correctly in place	Insert the tank correctly, pushing it as far as it will go until it clicks into place.
ON STEADILY	The grounds container (A11) is full	Empty the grounds container and drip tray (A15), clean and replace. Important: when removing the drip tray, the grounds container must be emptied, even if it contains few grounds. If this is not done, when you make the next coffees, the grounds container may fill up more than expected and clog the machine.
ON STEADILY	After cleaning, the grounds container (A11) has not been replaced	Remove the drip tray (A15) and insert the grounds container.
ON STEADILY	ON STEADILY	The coffee beans have run out	Fill the beans container (A3 - fig. 9).
FLASHING	The pre-ground coffee funnel (A4) is clogged	Empty the funnel with the help of the brush (C5) as described in section “17.8 Cleaning the pre-ground coffee funnel”.
ON STEADILY	The pre-ground coffee function has been selected without placing any pre-ground coffee in the funnel (A4)	Place pre-ground coffee in the funnel (fig. 12) or deselect the "pre-ground" function.
FLASHING	The pre-ground coffee funnel (A4) is clogged	Empty the funnel with the help of the brush (C5) as described in section “17.8 Cleaning the pre-ground coffee funnel”.
FLASHING	The machine must be descaled	The descaling procedure described in section \"18. Descaling\" needs to be performed.

Troubleshooting and error codes

\n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n

LIGHTS DISPLAYED	POSSIBLE CAUSE	REMEDY
FLASHING	Insufficient water in the tank (A17)	Fill the tank with water and/or insert it correctly, pushing it as far as it will go until it clicks into place.
FLASHING	The tank (A17) is missing or not correctly in place	Insert the tank correctly, pushing it as far as it will go until it clicks into place.
ON STEADILY	The grounds container (A11) is full	Empty the grounds container and drip tray (A15), clean and replace. Important: when removing the drip tray, the grounds container must be emptied, even if it contains few grounds. If this is not done, when you make the next coffees, the grounds container may fill up more than expected and clog the machine.
ON STEADILY	After cleaning, the grounds container (A11) has not been replaced	Remove the drip tray (A15) and insert the grounds container.
ON STEADILY	ON STEADILY	The coffee beans have run out	Fill the beans container (A3 - fig. 9).
FLASHING	The pre-ground coffee funnel (A4) is clogged	Empty the funnel with the help of the brush (C5) as described in section “17.8 Cleaning the pre-ground coffee funnel”.
ON STEADILY	The pre-ground coffee function has been selected without placing any pre-ground coffee in the funnel (A4)	Place pre-ground coffee in the funnel (fig. 12) or deselect the "pre-ground" function.
FLASHING	The pre-ground coffee funnel (A4) is clogged	Empty the funnel with the help of the brush (C5) as described in section “17.8 Cleaning the pre-ground coffee funnel”.
FLASHING	The machine must be descaled	The descaling procedure described in section \"18. Descaling\" needs to be performed.
