Manual for SC77 - Troubleshooting and error codes + PDF Download
Uploaded: April 7, 2025, 8:13 p.m.
Warranty Summary
This meter is warranted for one year against defects in material or workmanship and Fieldpiece will repair or replace the defective unit.
Operation Summary
- Works with Fieldpiece accessory heads for diverse measurements.
- Utilize NCV function for non-contact voltage detection.
- High voltage indicator alerts for voltages exceeding 30V.
- Employ clamp for AC current measurements.
- Measure capacitance for motor capacitors.
- Measure temperature using K-type thermocouple.
- Calibrate temperature for enhanced accuracy.
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| Risk of electric shock | Disconnect test leads before opening case. |
| NCV function failure | Test NCV function on a known live wire first. |
| Thermocouple/jacks damage | Avoid voltage > 30VAC/60VDC in °F mode. |
| Incorrect voltage readings | Remove thermocouple for voltage measurements. |
| Incorrect temperature readings | Disconnect test leads for temperature measurements. |
| Current overload (µA mode) | Do not apply voltage in microamps mode. |
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| Risk of electric shock | Disconnect test leads before opening case. |
| NCV function failure | Test NCV function on a known live wire first. |
| Thermocouple/jacks damage | Avoid voltage > 30VAC/60VDC in °F mode. |
| Incorrect voltage readings | Remove thermocouple for voltage measurements. |
| Incorrect temperature readings | Disconnect test leads for temperature measurements. |
| Current overload (µA mode) | Do not apply voltage in microamps mode. |
