Oven Operation Summary:

• Temperature Adjustment: Use the thermostat control knob to adjust oven heat between minimum and maximum.
• Heater Indication: A signal lamp indicates when heaters are operating and turns off when the desired temperature is reached.
• Pre-heating: Pre-heat the oven for five minutes before cooking.
• Oven Lamp: The oven lamp turns on when a function is selected.
• Upper and Lower Heater: For simultaneous cooking with both heaters.
• Lower Heater with Fan: For base heat and plate warming.
• Grill: Open oven door, attach heat deflection panel, and pre-heat grill for 5-10 minutes. Place food on oiled grid on upper shelf.
• Defrost: Place frozen food on middle grid, third shelf, with tray below to collect dripping water.
• Classical Cooking with Turbo: Use turbo fan with upper and lower heaters for consistent temperature, ideal for cakes and cookies.

Mechanical Timer:

• Turn knob clockwise to set time.
• Select temperature and function.
• Oven starts and timer counts down.
• Oven turns off automatically when timer reaches (•).
• 'M' setting for manual operation.

Digital Timer:

• Use to program cooking and ready times.
• Manual mode for basic time setting.
• Time of day adjustment available in manual mode.
• Child lock function to prevent accidental changes.
• Buzzer alarm setting and adjustment.
