Manual for DIY-300PS - Troubleshooting and error codes + PDF Download

Name: Manual for DIY-300PS - Troubleshooting and error codes + PDF Download
Brand: HAMPTON BAY

Brand: HAMPTON BAY

Category: Transformer

Manual Type:

Language:

Uploaded: April 8, 2025, 1:49 p.m.

Warranty Summary

HAMPTON BAY DIY-300PS transformer is warranted for two (2) years against defects in materials and workmanship under normal use.

The HAMPTON BAY DIY-300PS Transformer operation includes several modes:

Setting the Clock: Allows setting the device to local time for timer functions.
Manual Mode: Immediately turns lights on or off as needed.
Photocell Auto ON/OFF: Automatically turns lights on at dusk and off at dawn.
Photocell ON / TIME OFF: Turns lights on at dusk and off after a set duration.
Time ON/OFF: Allows setting specific times for lights to turn on and off.
Test Function: For testing landscape lighting installation.

Troubleshooting and error codes

Problem	Probable Cause
All of the lights fail to work	Check that the transformer power is on. Check if there is a loose connection at the transformer screw terminal with the cable. Check that the power switch is not in an OFF setting. Check the connector to make sure the wire barbs have pierced the landscape cable.
Only some lights work	Halogen or incandescent bulbs (if applicable) can be burned out. Use caution as the bulb can be hot.
The lights are on during the day	The photocell is mounted in a dark area which causes the lights to turn on unnecessarily.
The lights do not switch on at dusk	The photocell is mounted in an area that has too much constant light at night ,preventing the system from turning on.

Problem	Probable Cause
All of the lights fail to work	Check that the transformer power is on. Check if there is a loose connection at the transformer screw terminal with the cable. Check that the power switch is not in an OFF setting. Check the connector to make sure the wire barbs have pierced the landscape cable.
Only some lights work	Halogen or incandescent bulbs (if applicable) can be burned out. Use caution as the bulb can be hot.
The lights are on during the day	The photocell is mounted in a dark area which causes the lights to turn on unnecessarily.
The lights do not switch on at dusk	The photocell is mounted in an area that has too much constant light at night ,preventing the system from turning on.
