Manual for TE 75 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:49 p.m.
Manual Publish Date: 2013-07-07
Warranty Summary
Hilti warrants the tool for 12 months from the date of sale against defects in material and workmanship, provided it is operated and maintained according to instructions.
Insertion of TE-FY tool: Pull back locking sleeve, insert tool, and turn until drive grooves engage.
Rotary hammer drilling: Shift setting lever to rotary hammer drilling position.
Side handle and depth gauge adjustment: Loosen side handle, rotate, and tighten. Set depth gauge for precise drilling depth.
Chiselling: Insert chisel, shift setting lever to chiselling position, and adjust hammering power if needed.
Beginning work: Hold tool against work surface and press electronic switch.
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Service indicator lamp is lit | Indicates that the tool requires servicing | Carry out servicing at Hilti service center. |
Troubleshooting and error codes
| Problem | Possible Cause | Solution |
|---|---|---|
| Service indicator lamp is lit | Indicates that the tool requires servicing | Carry out servicing at Hilti service center. |
