Warranty Summary
The Honeywell Analytics warrants the XNX Universal Transmitter to be free from defects in material or workmanship for 36 months from shipment date.
The Honeywell XNX Foundation Fieldbus interface allows remote access to device features for displaying status, testing, calibrating, and configuring. A Device Descriptor (DD) file is necessary for interfacing. Configuration can be done locally or via Fieldbus, simplifying alarm level setup, time, units, and parameters. The device records significant events like alarms and recalibrations, which can be accessed through the Fieldbus interface. Testing methods are available for output inhibition, analog output exercise, and simulating alarms. Calibration menus support zero/span calibration and bump testing, displaying optical signal strength for Searchline EXCEL detectors.
Troubleshooting and error codes
| Error | Solution |
|---|---|
| Accept New Alarm Configuraiton | New alarm configuration for device is not accepted at device. Select Accept Alarm Configuration |
| Accept New Excel Fault Parameters | New Excel fault configuration for device is not accepted at device. Select Accept Configuration |
| LinkConfiguration | Not applicable |
| SimulationActive | Device is in simulation state. Exit simulation being performed on device. |
| DeviceFaultState | Device is in fault state. Refer fault code to dignostic fault on device. |
| Maint. Needed soon | Device is in warning state. Refer warning code to dignostic warning on device. |
| Maint. Needed Now | Device is in fault state. Refer fault code to dignostic fault on device. |
| Out Of Service | Device not in service. Contact HA or force device in Auto mode |
