Warranty Summary

IDYLIS 526011 dehumidifier has a limited appliance warranty for manufacturer's defects for a period of twelve months.
Download Manual

Start Operation:

  • Place upright on a flat, stable surface.
  • Plug into a suitable wall socket.
  • Ensure water tank is correctly located.

Water Tank:

  • Empty when 'Bucket Full' light illuminates.
  • Replace tank properly for continuous operation.

Dehumidifying Mode:

  • Press ON/OFF button to start.
  • Select desired humidity level (30%-90%).
  • Choose fan speed (High/Medium/Low).

Filter Cleaning:

  • Clean filter when indicator light glows (every 250 hours).
  • Clean with vacuum or wash and dry.
  • Replace filter after cleaning.

Troubleshooting and error codes

PROBLEM POSSIBLE CAUSE
Unit will not operate.
  • Check power cord connection.
  • Check electrical outlet for blown fuse.
  • Check if water tank is full (if yes, empty).
  • Check water tank is properly installed.
Dehumidifying capacity (moisture removal) low.
  • Ambient (room) temperature too low (below 41°F).
  • Poor air flow circulation/obstruction of front grille.
  • Air filter is dirty and/or blocked.
  • Relative humidity in surrounding environment very low.
Relative humidity setting not reached after long period of operation.
  • Check all doors and windows are closed.
  • Area/room is too large for the capacity of the dehumidifier.

Troubleshooting and error codes

PROBLEM POSSIBLE CAUSE
Unit will not operate.
  • Check power cord connection.
  • Check electrical outlet for blown fuse.
  • Check if water tank is full (if yes, empty).
  • Check water tank is properly installed.
Dehumidifying capacity (moisture removal) low.
  • Ambient (room) temperature too low (below 41°F).
  • Poor air flow circulation/obstruction of front grille.
  • Air filter is dirty and/or blocked.
  • Relative humidity in surrounding environment very low.
Relative humidity setting not reached after long period of operation.
  • Check all doors and windows are closed.
  • Area/room is too large for the capacity of the dehumidifier.
