Manual for T2 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:53 p.m.
Manual Publish Date: 2007-10
Warranty Summary
No warranty information is present in this operator's manual.
Vehicle Entry and Exit: Exercise caution, use three-point stance, and face inward when entering/exiting.
Cab Tilting: Electrically operated, tilts to 45 degrees with safety prop. Manual tilting to 90 degrees possible with hoist.
Seating: Adjust suspension seat for comfort and control, ensure head clearance.
Instrument Panel: Familiarize with gauges, controls, and indicators for operation monitoring.
Starting Engine: Set parking brake, place shifter in neutral, follow starting procedure.
Parking: Apply parking brake, place shifter in neutral, follow parking procedure.
Boom Operation: Hydraulically controlled, raise/lower boom in neutral and while stationary.
Trailer Spotting: Follow step-by-step guide for safe trailer handling and connection.
Troubleshooting and error codes
| Indicator Lamp | Condition | Action |
|---|---|---|
| High Exhaust Temperature Lamp | High exhaust temperatures exist. | Stop engine and allow exhaust system to cool. |
| DPF Regen Needed Lamp (Illuminated) | Diesel particulate filter requires regeneration within 2-6 hours. | Change to challenging duty cycle or perform "Stationary" Regeneration. |
| DPF Regen Needed Lamp (Flashing) | Regeneration not completed in timely manner. | Perform "Stationary" Regeneration within 1-2 hours. Engine power may reduce. |
| Flashing DPF Regen Needed & Check Engine Lamp | Diesel Particulate Filter needs immediate regeneration. | Perform "Stationary" regeneration immediately. Engine power will be reduced. |
| Stop Engine Lamp, Flashing DPF Regen Needed & Check Engine Lamp | DEF tank run dry or idled for one hour after dry. | Stop vehicle and refill DEF tank. Engine power and speed limited. |
| Malfunction Indicator Lamp (MIL) | Malfunction related to emissions control system detected. | Diagnose and service engine and aftertreatment system. |
| Diesel Exhaust Fluid (DEF) Lamp (Illuminated) | DEF level is low. | Refill DEF tank. |
| Diesel Exhaust Fluid (DEF) Lamp (Flashing) | DEF level has fallen below critical level. | Refill DEF tank. |
| Flashing DEF Lamp, Warning or Check Engine Lamp | DEF level is critically low. | Refill DEF tank. Power loss will occur. |
Troubleshooting and error codes
| Indicator Lamp | Condition | Action |
|---|---|---|
| High Exhaust Temperature Lamp | High exhaust temperatures exist. | Stop engine and allow exhaust system to cool. |
| DPF Regen Needed Lamp (Illuminated) | Diesel particulate filter requires regeneration within 2-6 hours. | Change to challenging duty cycle or perform "Stationary" Regeneration. |
| DPF Regen Needed Lamp (Flashing) | Regeneration not completed in timely manner. | Perform "Stationary" Regeneration within 1-2 hours. Engine power may reduce. |
| Flashing DPF Regen Needed & Check Engine Lamp | Diesel Particulate Filter needs immediate regeneration. | Perform "Stationary" regeneration immediately. Engine power will be reduced. |
| Stop Engine Lamp, Flashing DPF Regen Needed & Check Engine Lamp | DEF tank run dry or idled for one hour after dry. | Stop vehicle and refill DEF tank. Engine power and speed limited. |
| Malfunction Indicator Lamp (MIL) | Malfunction related to emissions control system detected. | Diagnose and service engine and aftertreatment system. |
| Diesel Exhaust Fluid (DEF) Lamp (Illuminated) | DEF level is low. | Refill DEF tank. |
| Diesel Exhaust Fluid (DEF) Lamp (Flashing) | DEF level has fallen below critical level. | Refill DEF tank. |
| Flashing DEF Lamp, Warning or Check Engine Lamp | DEF level is critically low. | Refill DEF tank. Power loss will occur. |
