Manual for Z407 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:51 p.m.
Manual Publish Date: 2020-01-01
Warranty Summary
Warranty information is not provided in this setup manual.
To set up the LOGITECH Z407 speakers:
- Connect satellite speakers to the subwoofer using RCA cables (right satellite to blue jack, left satellite to gray jack).
- Connect the power cord to an electrical outlet.
- For Bluetooth connection, activate Bluetooth on your device, press and hold the Bluetooth button on the control dial (2 sec), and select "Logi Z407" from your device list.
- For 3.5mm cable connection, connect one end to the subwoofer and the other to your device's audio jack, then press the wired input button.
- For USB cable connection, connect one end to the subwoofer and the other to your device's USB-A port, then press the wired input button.
- Control volume, bass, play/pause, skip, and rewind using the wireless control dial.
Troubleshooting and error codes
| Usage | Description | LED Status | LED Color | Sonification | Actions |
|---|---|---|---|---|---|
| 1 | Default connected to the speaker | Solid | Blue | ||
| 2 | Waiting for connection to the speaker | Slow blink | Blue | ||
| 3 | Dial link lost | Slow blink | White (USB) / Blue (BT) / Purple (AUX) | ||
| 4 | New dial connects to the speaker | Solid | Blue | V | |
| 5 | Connected / Normal Operation | Solid | White (USB) / Blue (BT) / Purple (AUX) | ||
| 6 | Bluetooth pairing to device | Fast blinking | Blue | V | Long press Bluetooth button for 2 sec. |
| 7 | Bluetooth connected | Solid | Blue | V | |
| 8 | Bluetooth disconnected | Solid | Blue | V | |
| 9 | Play / Pause | White (USB) / Blue (BT) | One press | ||
| 10 | Mute / Unmute | Purple (AUX) | One press | ||
| 11 | Track forward | Solid | White (USB) / Blue (BT) | Double press | |
| 12 | Rewind (Track backward) | White (USB) / Blue (BT) | Triple press | ||
| 13 | Adjust the system volume | Rotate the dial | |||
| 14 | Adjust the bass volume | Solid | White (USB) / Blue (BT) / Purple (AUX) | Long press 2 sec. to enter and exit bass mode | |
| 15 | Max volume | V | |||
| 16 | Max bass | V | |||
| 17 | Low Battery | Solid | Red | ||
| 18 | Extreme low battery | Fast blink | Red | ||
| 19 | Reset all settings | Fast blink → Solid | Status color → Blue | V | Press & hold BT and wired input button for 8 sec. |
