Warranty Summary
Mastercraft 046-0265-2 garage door opener motor has an 8 year warranty, parts have a 2 year warranty, and accessories have a 1 year limited warranty against defects.
Operating the Door:
- Activate by pressing the wall console or remote.
- Door behavior depends on its current state (open, closed, moving, obstructed).
- Opener light turns on when activated and off automatically after 3 minutes.
- Manual light control available on the wall console.
Remote Control:
- Hold the button until the door moves.
Keypad Operation:
- Enter pin code plus [#] for single door operation.
- Enter pin code plus [#] plus [door number] for multiple doors.
Manual Operation:
- Pull red trolley release handle to disengage during power failure or obstruction.
- Flip trolley lever up to re-engage.
Troubleshooting and error codes
| LED Light Flashing | LED Display Flashing | Symptom | Solution |
|---|---|---|---|
| 3 Flashes | L L |
The wall console is in lock mode. The remote controls are deactivated. | Unlock the wall console. |
| 5 Flashes | 0 0 |
Overtime. The motor is running continuously over 30 seconds in one direction. | Ensure the opener is correctly installed and attached to the garage door. Adjust the travel limit. |
| 10 Flashes | 6 6 |
Safety beam sensor blocked. | Check safety beam sensor alignment and obstructions. |
| 15 Flashes | F F |
The door is not fully open or fully closed. | Check for obstructions, re-adjust travel limits and force. |
| Continuous Flashing | C C |
Wall console wire shorted. | Check wall console wires for a short. |
Troubleshooting and error codes
| LED Light Flashing | LED Display Flashing | Symptom | Solution |
|---|---|---|---|
| 3 Flashes | L L |
The wall console is in lock mode. The remote controls are deactivated. | Unlock the wall console. |
| 5 Flashes | 0 0 |
Overtime. The motor is running continuously over 30 seconds in one direction. | Ensure the opener is correctly installed and attached to the garage door. Adjust the travel limit. |
| 10 Flashes | 6 6 |
Safety beam sensor blocked. | Check safety beam sensor alignment and obstructions. |
| 15 Flashes | F F |
The door is not fully open or fully closed. | Check for obstructions, re-adjust travel limits and force. |
| Continuous Flashing | C C |
Wall console wire shorted. | Check wall console wires for a short. |
