Warranty Summary

No warranty information provided in this manual.

Setting Current Time

  1. Press and hold the CLOCK button.
  2. Simultaneously press WEEK, HOUR, or MIN buttons to set the current day and time.
  3. Release both buttons to save the current time.
  4. Repeat steps if the time is incorrect.

Setting Programs

  1. Press the TIMER button once (LCD shows ON_1).
  2. Press WEEK button to select days, then HOUR and MIN to set the ON time.
  3. Press TIMER again (LCD shows OFF_1).
  4. Repeat step 2 to set the OFF time.
  5. Press TIMER to proceed to set subsequent programs.
  6. Press CLOCK button to finish setting programs.

Troubleshooting and error codes

No troubleshooting table is present in this manual. If you experience issues, consult a qualified electrician as advised in the manual.

Troubleshooting and error codes

No troubleshooting table is present in this manual. If you experience issues, consult a qualified electrician as advised in the manual.
