Manual for BRAVOS XL - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:50 p.m.
Manual Publish Date: 2010-06-01
Warranty Summary
MAYTAG BRAVOS XL washer has a one year limited warranty for parts and labor, and a second through tenth year limited warranty on drive motor and wash basket only (labor not included).
To operate the MAYTAG BRAVOS XL washer, follow these steps:
- Sort and prepare laundry.
- Add single-dose laundry packet or fabric softener crystals (if desired) directly to the basket.
- Load laundry into the washer, ensuring it's evenly distributed around the washplate.
- Add HE detergent to the detergent dispenser.
- Add liquid chlorine bleach or Oxi product to the bleach dispenser if needed.
- Add liquid fabric softener to the fabric softener dispenser if desired and select the Fabric Softener option.
- Press the POWER/CANCEL button to turn on the washer.
- Select the desired wash cycle using the Wash Cycle knob.
- Select cycle modifiers such as Wash Temp, Spin Speed, and Soil Level as needed.
- Select cycle options like Water Save Spray Rinse, Oxi Treat Stains, Clean Boost with Heater, Extra Rinse, and Fabric Softener as desired.
- Press START/PAUSE to begin the wash cycle.
Troubleshooting and error codes
| If you experience | Possible Causes | Solution |
|---|---|---|
| Vibration, rocking, or "walking" | Feet may not be in contact with the floor and locked. | Front and rear feet must be in firm contact with floor, and washer must be level to operate properly. Jam nuts must be tight against the bottom of the cabinet. |
| Washer may not be level. | Check floor for flexing or sagging. If flooring is uneven, a 3/4" (19 mm) piece of plywood under your washer will reduce sound. See "Level Washer" in the Installation Instructions. | |
| Vibration during spinning or washer stopped with uL error code flashing | Load could be unbalanced. | Load garments in loose heaps evenly around the washplate. Do not load garments directly over the center of the washplate. Adding wet items to washer or adding more water to basket could unbalance washer. |
| Clicking or metallic noises | Objects caught in washer drain system. | Empty pockets before washing. Loose items such as coins could fall between basket and tub or may block pump. It may be necessary to call for service to remove items. |
| Gurgling or humming | Washer may be draining water. | It is normal to hear the pump making a continuous humming sound with periodic gurgling or surging as final amounts of water are removed during the spin/drain cycles. |
| Not enough water in washer | Load not completely covered in water. | This is normal operation for an HE low-water washer. The load will not be completely under water. The washer senses load sizes and adds correct amount of water for optimal cleaning. See "What's New under the Lid." |
Troubleshooting and error codes
| If you experience | Possible Causes | Solution |
|---|---|---|
| Vibration, rocking, or "walking" | Feet may not be in contact with the floor and locked. | Front and rear feet must be in firm contact with floor, and washer must be level to operate properly. Jam nuts must be tight against the bottom of the cabinet. |
| Washer may not be level. | Check floor for flexing or sagging. If flooring is uneven, a 3/4" (19 mm) piece of plywood under your washer will reduce sound. See "Level Washer" in the Installation Instructions. | |
| Vibration during spinning or washer stopped with uL error code flashing | Load could be unbalanced. | Load garments in loose heaps evenly around the washplate. Do not load garments directly over the center of the washplate. Adding wet items to washer or adding more water to basket could unbalance washer. |
| Clicking or metallic noises | Objects caught in washer drain system. | Empty pockets before washing. Loose items such as coins could fall between basket and tub or may block pump. It may be necessary to call for service to remove items. |
| Gurgling or humming | Washer may be draining water. | It is normal to hear the pump making a continuous humming sound with periodic gurgling or surging as final amounts of water are removed during the spin/drain cycles. |
| Not enough water in washer | Load not completely covered in water. | This is normal operation for an HE low-water washer. The load will not be completely under water. The washer senses load sizes and adds correct amount of water for optimal cleaning. See "What's New under the Lid." |
