Warranty Summary

Keep proof of original purchase date with this guide to establish the warranty period.
Download Manual

Basic Operation Summary:

  • Power ON/OFF: Use the ON/OFF button.
  • Temperature Adjustment: Not directly adjustable by user except via preset modes.
  • Modes:
    • ON Mode: Normal chilling (37°F/2°C to 39°F/4°C). Default mode.
    • OFF Mode: Warmer chilling (58°F/14°C to 61°F/16°C).
    • SNOOZE Mode: Energy saving mode for 8 hours (50°F/10°C).
    • QUICK COOL Mode: Rapidly chills to 34°F/1°C then switches to ON mode.
  • Display: Shows current temperature and operation status.

Troubleshooting and error codes

Problem Possible Cause and Solution
SmartFridge fails to operate
  • Check power cord connection.
  • Check power supply outlet (fuse/breaker).
  • Ensure SmartFridge is working.
Continuous operation of cooling system
  • Door frequently opened or left open.
  • Door not properly closed (sagging/gasket issues).
  • Overloaded with fresh food.
  • Inadequate compressor ventilation.
Ice formation on inner rear wall
  • Normal up to 0.20" (5mm), manually defrost if thicker.
  • Check door seal, door opening frequency, warm food storage, food touching back wall.
Water leaking
  • Clogged discharge water outlet.
  • Defrost water dripping over channel.
Noise
  • Normal compressor noise.
  • Check level installation, cabinet touching, accessories placement, rattling items.
