Warranty Summary

For warranty information, please see the Limited Warranty sheet included with your product.
Download Manual

Basic Operation Summary:

  • Resetting the microprocessor: Turn ignition OFF, press RESET.
  • Starting up the unit: Start the engine.
  • Using the touch panel: Touch screen gently with fingers.
  • Common touch panel keys: Play/Pause, Skip tracks, Fast reverse/forward, Stop, Text information, Return, Close.

Troubleshooting and error codes

Problem Cause and Solution
A black screen is displayed, and operation is not possible using the touch panel keys. Power off mode is on. - Press any button on this product to release the mode.
CD or DVD playback is not possible. The disc is inserted upside down. Insert the disc with the label upward. The disc is dirty. Clean the disc. The disc is cracked or otherwise damaged. Insert a normal, round disc. The files on the disc are in an irregular file format. Check the file format. The disc format cannot be played back. Replace the disc. The loaded disc is a type this product cannot play. Check what type of disc it is.
The screen is covered by a caution message and the video cannot be shown. The parking brake lead is not connected or the parking brake is not applied. Connect the parking brake lead correctly, and apply the parking brake. The parking brake interlock is activated. Park your vehicle in a safe place and apply the parking brake.
No sounds are produced. The volume level will not rise. The system is performing still, slow motion, or frame-by-frame playback with DVD-Video. There is no sound during still, slow motion, or frame-by-frame playback with DVD-Video. The system is paused or performing fast reverse or forward during the disc playback. For the media other than music CD (CD-DA), there is no sound on fast reverse or forward.

Troubleshooting and error codes

Problem Cause and Solution
A black screen is displayed, and operation is not possible using the touch panel keys. Power off mode is on. - Press any button on this product to release the mode.
CD or DVD playback is not possible. The disc is inserted upside down. Insert the disc with the label upward. The disc is dirty. Clean the disc. The disc is cracked or otherwise damaged. Insert a normal, round disc. The files on the disc are in an irregular file format. Check the file format. The disc format cannot be played back. Replace the disc. The loaded disc is a type this product cannot play. Check what type of disc it is.
The screen is covered by a caution message and the video cannot be shown. The parking brake lead is not connected or the parking brake is not applied. Connect the parking brake lead correctly, and apply the parking brake. The parking brake interlock is activated. Park your vehicle in a safe place and apply the parking brake.
No sounds are produced. The volume level will not rise. The system is performing still, slow motion, or frame-by-frame playback with DVD-Video. There is no sound during still, slow motion, or frame-by-frame playback with DVD-Video. The system is paused or performing fast reverse or forward during the disc playback. For the media other than music CD (CD-DA), there is no sound on fast reverse or forward.
