Warranty Summary

No warranty information is included in this owner's manual.
Download Manual
Power ON/OFF
  • Press the SOURCE button to turn the unit on.
  • Press and hold the SOURCE button to turn the unit off.
Selecting a Source
  • Press the SOURCE button repeatedly to cycle through available sources (Tuner, Built-in CD player, AUX).
Adjusting the Volume
  • Turn the VOLUME knob to adjust the sound level.
Tuner Operations
  • Press SOURCE to select the tuner.
  • Press BAND to select FM or AM band.
  • Briefly press the seek buttons (a/b) for manual tuning.
  • Press and hold seek buttons (a/b) for seek tuning.
Built-in Player Operations
  • Insert a CD into the disc loading slot to start playback.
  • Press the eject button to eject the CD.
  • Use buttons to skip tracks, fast forward/reverse, pause, repeat, random play, and scan.

Troubleshooting and error codes

Message Cause Action
ERROR-11, 12, 17, 30 Dirty disc Clean disc.
ERROR-11, 12, 17, 30 Scratched disc Replace disc.
ERROR-10, 11, 12, 15, 17, 30, A0 Electrical or mechanical Turn the ignition switch OFF and back ON, or switch to a different source, then back to the CD player.
ERROR-15 The inserted disc does not contain any data Replace disc.
ERROR-22, 23 The CD format cannot be played back Replace disc.
NO AUDIO The inserted disc does not contain any files that can be played back Replace disc.
PROTECT All the files on the inserted disc are secured by DRM Replace disc.
SKIPPED The inserted disc contains WMA files that are protected by DRM Replace disc.

Troubleshooting and error codes

Message Cause Action
ERROR-11, 12, 17, 30 Dirty disc Clean disc.
ERROR-11, 12, 17, 30 Scratched disc Replace disc.
ERROR-10, 11, 12, 15, 17, 30, A0 Electrical or mechanical Turn the ignition switch OFF and back ON, or switch to a different source, then back to the CD player.
ERROR-15 The inserted disc does not contain any data Replace disc.
ERROR-22, 23 The CD format cannot be played back Replace disc.
NO AUDIO The inserted disc does not contain any files that can be played back Replace disc.
PROTECT All the files on the inserted disc are secured by DRM Replace disc.
SKIPPED The inserted disc contains WMA files that are protected by DRM Replace disc.
