Warranty Summary

PowerSmart warrants this consumer power tool to be free from defects for two (2) years from purchase date for home use.
Download Manual

STARTING: Refer to the ENGINE manual for engine operation instructions.

CLEARING SNOW:

  1. Start the engine and ensure the path is clear.
  2. Adjust the chute outlet.
  3. Engage the auger control handle.
  4. Set speed and direction using the control lever.
  5. Engage the drive control handle and direct the snow thrower.

STOPPING:

  1. Engage auger for 30 seconds to clear snow.
  2. Stop the auger.
  3. Set engine switch to OFF.
  4. Remove snow from the snow thrower.

Troubleshooting and error codes

Problem Causes Remedy
Engine Fails to Start (Engine cranks over) Engine ignition switch in OFF position Position engine ignition switch to ON
Engine Fails to Start (Engine cranks over) Spark plug wire disconnected Connect wire to spark plug
Engine Fails to Start (Engine cranks over) Faulty spark plug Clean, adjust gap, or replace spark plug, see Engine Operator's manual
Engine Fails to Start (Engine cranks over) Engine flooded with fuel Discontinue choke or primer use, clean or replace spark plug.
Engine Fails to Start (Engine cranks over) Safety key not inserted in engine ignition Insert key fully into the switch
Engine electric starter will not crank engine Extension cord is not properly attached to electric starter terminal Re-insert extension cord into electric starter terminal.
Engine runs erratic, stalls or seems low on power Fuel incorrect, old or stale Empty and clean fuel tank & carburetor, refill with fresh, clean gasoline.
No forward or reverse drive movement when drive handle engaged Drive belt loose or damaged Check drive belt tension pulley for damage or incorrect tension, repair as necessary. Replace drive belt.
