Brand: PRO-FORM
Category: Treadmill
Manual Type:
Language:
Manual for 745CS 831.299470 - Troubleshooting and error codes + PDF Download
Uploaded: April 8, 2025, 1:53 p.m.
Manual Publish Date: 2000
Warranty Summary
For 90 days from purchase date, Sears will repair or replace the PROFORM 745CS Treadmill Exerciser free of charge if failure occurs due to defect in material or workmanship.
This ProForm 745CS 831.299470 treadmill user manual provides instructions for safe and effective operation. To start, ensure the power cord is correctly plugged into a grounded outlet and surge suppressor. Turn on the power switch and insert the key into the console. Select manual mode or a personal trainer program. Start the treadmill by pressing START or SPEED buttons and adjust speed and incline as needed. Monitor your workout using the console displays and optionally measure heart rate via hand sensors. When finished, stop the treadmill, adjust incline to the lowest level, remove the key, and turn off the power switch. Always follow safety precautions and guidelines for optimal use.
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| The power does not turn on | a. Ensure power cord is plugged into a grounded outlet and surge suppressor. b. Verify key is fully inserted into the console. c. Check and reset the circuit breaker. d. Ensure on/off switch is in the 'on' position. |
| The power turns off during use | a. Check and reset the circuit breaker. b. Ensure power cord is plugged in. c. Reinsert the key fully into the console. d. Make sure that the on/off switch is in the on position. |
| The speed display on the console does not function properly | a. Adjust the Reed Switch and Magnet gap to approximately 1/8" on the Pulley. |
| The walking belt slows when walked on | a. Use a UL-listed surge suppressor, rated at 15 amps. b. Loosen the walking belt by turning rear roller bolts counterclockwise. |
| The walking belt is off-center | a. Adjust rear roller bolts to center the walking belt. |
| The walking belt slips when walked on | a. Tighten the walking belt by turning rear roller bolts clockwise. |
| The incline of the treadmill does not change correctly | a. Recalibrate the incline by removing and re-inserting the key while pressing an INCLINE button. |
Troubleshooting and error codes
| Problem | Solution |
|---|---|
| The power does not turn on | a. Ensure power cord is plugged into a grounded outlet and surge suppressor. b. Verify key is fully inserted into the console. c. Check and reset the circuit breaker. d. Ensure on/off switch is in the 'on' position. |
| The power turns off during use | a. Check and reset the circuit breaker. b. Ensure power cord is plugged in. c. Reinsert the key fully into the console. d. Make sure that the on/off switch is in the on position. |
| The speed display on the console does not function properly | a. Adjust the Reed Switch and Magnet gap to approximately 1/8" on the Pulley. |
| The walking belt slows when walked on | a. Use a UL-listed surge suppressor, rated at 15 amps. b. Loosen the walking belt by turning rear roller bolts counterclockwise. |
| The walking belt is off-center | a. Adjust rear roller bolts to center the walking belt. |
| The walking belt slips when walked on | a. Tighten the walking belt by turning rear roller bolts clockwise. |
| The incline of the treadmill does not change correctly | a. Recalibrate the incline by removing and re-inserting the key while pressing an INCLINE button. |
